AGM Secutor LRF 35-384 THERMAL SIGHTS
AGM Secutor LRF 35-384 Thermal Weapon Sight 3x 35mm
AGM Secutor LRF 35-384 is a compact thermal weapon sight built for users who need a practical long-range-capable thermal platform with integrated laser ranging and a more field-oriented power system. It combines a 384×288, 12 μm VOx uncooled focal plane array sensor, NETD below 20 mK, a 35 mm F1.0 lens, and a 1024×768 OLED display, delivering a clear thermal image for hunting, predator control, and professional applications where reliable detection and ranging matter.
One of the defining characteristics of the Secutor LRF series is its built-in laser rangefinder with a maximum range of 1000 m and ±4 m accuracy, paired with a digital compass and CR123A battery-based power system. This combination makes the optic especially practical for users who value battery availability, field replacement simplicity, and more situational awareness when working at distance.
The sight also includes picture-in-picture mode, highest temperature spot tracking, defective pixel correction, digital boresight adjustment, WiFi hotspot, standby mode, burn prevention, Shot Activated Recording, onboard video and audio recording, image capture, and 16 GB of built-in EMMC storage. These features make it more than a simple observation optic and give experienced users a more flexible thermal weapon sight for regular field use.
With 3x base magnification, 3× – 24× total magnification, a 7.5° × 5.6° field of view, and 1800 m detection range on a 6-foot object, the Secutor LRF 35-384 is especially suitable for users who want a compact thermal scope with integrated ranging and a straightforward battery format. It is a strong option for hunting rifles, predator setups, and tactical users who need practical thermal performance with competitive pricing and delivery across Europe from Professional Optics.
Technical specifications AGM Secutor LRF 35-384
Specification | Value |
Model | AGM Secutor LRF 35-384 |
Product type | Thermal weapon sight |
Detector type | 12μm VOx Uncooled Focal Plane Array |
Resolution | 384 × 288 |
Refresh rate | 50 Hz |
Response waveband | 8 μm to 14 μm |
NETD | Less than 20 mK (@25°C), F#=1.0 |
Lens system | 35 mm; F1.0 |
Field of view | 7.5° × 5.6° |
Magnification | 3× – 24× |
Digital zoom | 1×, 2×, 4×, 8× |
Detection range | 1,800 m/yd |
Eye relief | 45 mm |
Exit pupil | 6 mm |
Diopter adjustment | -5 to +3 dpt |
Display | 1024×768, 0.39 inch, OLED |
FFC | Auto, Manual, External Correction |
Palettes | Black Hot, White Hot, Red Hot, Fusion |
Reticle | 10 types, 4 colors, on/off |
Boresight adjustment | Digital Controlled |
Laser rangefinder | Up to 1000 m, ±4 m accuracy |
Laser wavelength | 905 nm |
Laser safety class | Class 1 |
Highest temperature spot tracking | Yes |
Defective pixel correction | Yes |
WiFi hotspot | Yes |
Standby mode | Yes |
Picture in Picture | Yes |
Burn prevention | Yes |
Built-in storage | 16 GB EMMC |
Video/audio recording | Yes |
Image capture | Yes |
Shot Activated Recording | Yes |
Battery type | Four CR123A Lithium batteries |
Battery operating time | More than 7 hours, WiFi off |
External power | 5 VDC/2 A, USB Type-C |
Working temperature | -30°C to 55°C |
Protection level | IP67 |
Max recoil | 1,000 g / 0.4 ms |
Dimensions | 215 × 101 × 74 mm, without mount |
Weight | 0.6 kg, without mount and battery |
For experienced users, the main appeal of the Secutor LRF 35-384 is its balance between thermal capability, integrated ranging, and a very practical CR123A-based power system. It is especially relevant for users who prefer field-replaceable batteries and want a compact thermal sight that stays simple to support during long nights or remote hunting trips.
The integrated digital compass is also a meaningful addition for users who work in larger open areas or in more tactical scenarios where orientation and directional awareness matter. Combined with the 1000 m laser rangefinder and digital boresight adjustment, it makes the optic more useful for repeatable and structured field work than many simpler thermal sights.
Another strong point is that the Secutor LRF keeps the feature set practical rather than overloaded. Video and audio recording, SAR, hotspot connectivity, multiple reticles, PIP mode, and hotspot tracking cover the functions that experienced users actually use in hunting and field evaluation without forcing a bulkier scope format.
The sight supports dedicated accessory mounts. AGM-2125 ADM quick release mount is not included.
FAQ
What sensor does the AGM Secutor LRF 35-384 use?
It uses a 384 × 288, 12 μm VOx uncooled focal plane array sensor.
Does it have an integrated laser rangefinder?
Yes, it includes a built-in laser rangefinder with a maximum range of 1000 m and ±4 m accuracy.
Does it have a digital compass?
Yes, the Secutor LRF series includes a digital compass.
What battery system does it use?
It uses four CR123A lithium batteries.
Does it support recording?
Yes, it supports onboard video and audio recording, image capture, and Shot Activated Recording.
How much built-in storage does it have?
It has 16 GB of built-in EMMC storage.
Does it support external power?
Yes, it supports 5 VDC/2 A external power through USB Type-C.
